USGS Release Date: March 16, 2017

USGS image of the week shows Ethiopia’s erupting Gateway to Hell.

USGS Image of the Week is a continuing series of image reposts from the USGS Earth Resources and Observation Science Center. From the artistry of Earth imagery to natural and human-caused land change over time, visit USGS every Saturday to finish your week with a visual flourish!

In this view of Ethiopia’s Erta Ale, taken on January 10, 2017, Landsat shows lava welling up in the caldera. Credit: USGS/NASA Landsat Program.(Public domain.)

The Image: Landsat Detects Eruptions at Ethiopian Volcano


Landsat 8’s shortwave infrared (SWIR) band is useful in viewing recent eruptions at Erta Ale volcano in northern Ethiopia near the Eritrea border. The volcano’s name means “smoking mountain,” and its southernmost vent is referred to as “the gateway to hell.” Both names acknowledge its long-term volcanic activity since the early 1900s, and the persistent filling and draining of lava lakes within its main crater rim. The lava lakes have been filled most recently since the 1960s.

In this view of Ethiopia’s Erta Ale, taken on February 11, 2017, Landsat shows increased amounts of lava flowing down the sides of the volcano. Credit: USGS/NASA Landsat Program.(Public domain.)

Like other shield volcanoes, Erta Ale has gentle slopes and a wide base of about 25 miles in diameter. Shield volcanoes do not erupt explosively. Instead, the basaltic lava is very fluid and erupts like fountains in the lava lakes and along fissures, flowing like streams down the sides. Darker streaks in these recently acquired Landsat images are some of the previously erupted, cooled, and solidified lava flows.

The elliptical summit crater contains several smaller pit craters, and the current lava lake is in one of these. The red spot in the January 10 image is a SWIR signal associated with the location of the most recent lava lake. The February 11 image, however, shows out-gassing of that lava lake and other hot spots on the southeastern slope of the volcano. According to the Global Volcanism Program(link is external), new fissures opened on January 21. Landsat’s SWIR signal infers increased temperatures where new lava is either at very shallow depths below the surface or gurgling to the surface.

Hungry for some science, but you don’t have time for a full-course research plate? Then check out USGS Science Snippets.

This entry was originally posted in USGS homepage.
